Synergy 21 LED U-profiel ALU114 PMMA opale diffusor (S21-LED-PR20210)

The Synergy 21 LED U-Profile ALU114 with PMMA opal diffuser is a high-quality aluminum profile designed for LED strip integration. Ideal for indoor applications such as furniture, display lighting, and kitchens, this profile offers excellent heat dissipation and a sleek silver finish. The opal diffuser provides a soft, diffuse light output with approximately 80% light transmission, ensuring uniform illumination without hotspots.

Advantages

This profile combines durability with aesthetic appeal. The anodized aluminum housing ensures long-lasting performance and efficient thermal management, extending the life of your LED strips. The PMMA diffuser is UV resistant and can be cut to size, offering flexibility for custom projects. Surface mount installation is straightforward, and the profile is compatible with both flexible and rigid LED strips up to 12.2 mm width.

Suitable for

• Indoor accent lighting
• Furniture and cabinet lighting
• Display case illumination
• Kitchen under-cabinet lighting
• Architectural linear lighting

Key specifications

• Profile Type: U-Profile / Flat Profile
• Material: Anodized Aluminum
• Color: Silver
• Diffuser Material: PMMA (Polymethyl methacrylate)
• Diffuser Type: Opal, Diffuse
• Light Transmission: ~80%
• Max. LED Strip Width: 12.2 mm
• Outer Width: 17.5 mm
• Outer Height: 7 mm
• Length: 1000 mm
• Mounting: Surface Mount
• Protection Class: IP20
• Cuttable: Yes (profile and diffuser)

Recommendations

For a complete installation, use compatible end caps and mounting clips (sold separately). Ensure the LED strip width does not exceed 12 mm for proper fit. This profile is designed for indoor use only.
