Telegärtner H02050A0104 Cat.6A afgeschermde RJ45-datamodule, gereedschapsloze IDC, 10G, IP20

High-speed data transmission in industrial and office environments demands reliable connectivity that can handle 10 Gigabit Ethernet without signal degradation. The Telegärtner H02050A0104 RJ45 data module meets this need with Cat.6A (Class EA) performance, ensuring stable links up to 500 MHz for bandwidth-intensive applications.

Who is it for

Network installers and IT professionals who require a robust, tool-less termination solution for shielded cabling systems. Ideal for patch panels, wall outlets, and consolidation points in structured cabling projects.

Main features

• Cat.6A (Class EA) performance supports 10GBASE-T up to 500 MHz
• Shielded design (FTP/STP) with die-cast zinc housing for EMI protection
• Tool-less IDC termination for solid 22-24 AWG and stranded 22-26 AWG conductors
• Universal T568A/B wiring scheme for flexible installation
• Gold-plated contacts (min. 0.8 µm) ensure reliable connections over 750 mating cycles
• Compact dimensions: 160 mm x 30 mm x 110 mm, IP20 rated for indoor use

Specifications

• Product Type: RJ45 Data Module
• Category: Cat.6A (Class EA)
• Shielding: Shielded (FTP/STP)
• Connector Type: RJ45 Jack
• Wiring Scheme: T568A/B (Universal)
• Termination Type: IDC, Tool-less
• Ingress Protection: IP20
• Transmission Performance: 10 Gigabit Ethernet (10GBASE-T)
• Frequency Range: Up to 500 MHz
• Mounting Type: AMJ-S Module
• Housing Material: Die-cast zinc
• Contact Plating: Gold (min. 0.8 µm) over nickel
• Conductor Gauge (Solid): 22-24 AWG
• Conductor Gauge (Stranded): 22-26 AWG
• Mating Cycles: > 750
• Operating Temperature: -40 °C to +70 °C
• Standards Compliance: ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2

Tips

For optimal performance, pair with Telegärtner AMJ-S patch panels and maintain proper cable twist up to the termination point. Use the tool-less IDC mechanism to speed up installation while ensuring consistent contact force.
