Teltonika PR1KCO28 MIMO directionele paneelantenne 28 dBi SMA

The Teltonika PR1KCO28 is a high-performance MIMO directional panel antenna designed for demanding wireless applications. With a peak gain of up to 28 dBi and support for 2x2 MIMO, this antenna ensures robust signal strength and reliability across multiple frequency bands, including 617-960 MHz, 1710-2700 MHz, 3300-4200 MHz, and 4900-6000 MHz. Ideal for LTE, 5G, and other cellular networks, it features dual-polarized (vertical and horizontal) operation, low VSWR, and an IP67-rated enclosure for outdoor use.

Advantages

Exceptional gain of up to 28 dBi ensures long-range connectivity. Dual-polarized design improves signal diversity and reduces interference. Wide frequency coverage supports multiple network generations. Rugged IP67 housing withstands harsh weather conditions. Includes two 10-meter low-loss cables for flexible installation.

Suitable for

• Outdoor cellular base stations and repeaters
• LTE/5G fixed wireless access (FWA) deployments
• Industrial IoT and M2M communication
• Rural and remote area connectivity
• Point-to-point and point-to-multipoint links

Key specifications

• Antenna Type: Directional Panel
• MIMO: 2x2
• Frequency Range: 617-960 MHz, 1710-2700 MHz, 3300-4200 MHz, 4900-6000 MHz
• Peak Gain: 28 dBi
• Polarization: Dual (Vertical & Horizontal)
• VSWR: <1.5
• Impedance: 50 Ohm
• Connector: 2 x SMA Male
• Cable Length: 2 x 10 m (CFD200 Low-Loss)
• Mounting: Pole/Wall
• IP Rating: IP67
• Operating Temperature: -40°C to +70°C

Recommendations

For optimal performance, pair this antenna with Teltonika routers or gateways that support MIMO. Ensure proper grounding and lightning protection during installation. Use high-quality SMA connectors and cables to minimize signal loss.
