TSC TE200 UK, 8 punten/mm (203dpi), TSPL-EZ, USB - labelprinter - labelprinter

Label printing can be a bottleneck when your printer is slow, unreliable, or limited to one media type. The TSC TE200 UK eliminates these frustrations with a robust, dual-mode thermal printing engine that handles both direct thermal and thermal transfer media, ensuring crisp, durable labels for shipping, retail, healthcare, and logistics. With a 203 dpi resolution and a rapid 152.4 mm/s print speed, it powers through high-volume jobs without sacrificing clarity, while the 108 mm print width accommodates standard 4-inch labels. The TSPL-EZD language simplifies integration, and USB connectivity offers plug-and-play setup, with optional Ethernet and RS-232 for flexible networking. A 400 MHz processor and 16 MB RAM keep data flowing smoothly, while the double-wall clamshell design protects internal components in demanding environments. From barcode labels to asset tags, the TE200 UK delivers consistent, professional results every time.

Who is it for

This printer is ideal for small to medium businesses, e-commerce sellers, warehouse operators, and healthcare facilities that need reliable label output without complex setup. It suits users printing shipping labels, product tags, barcode labels, and wristbands in moderate to high volumes. Its dual thermal technology makes it versatile for both short-term direct thermal labels and long-lasting thermal transfer labels that resist heat, chemicals, and abrasion.

Main features

• Dual print technology: direct thermal and thermal transfer for flexible media options
• 203 dpi resolution (8 dots/mm) for sharp text, barcodes, and graphics
• Fast print speed up to 152.4 mm/s (6 ips) to boost productivity
• Wide 108 mm print width supports standard 4-inch labels
• USB 2.0 standard, with optional Ethernet, RS-232, and USB Host for connectivity
• TSPL-EZD printer language for easy integration with existing software
• 400 MHz 32-bit RISC processor and 16 MB SDRAM for smooth operation
• Supports 1D and 2D barcodes, including QR codes, for versatile labeling
• Double-wall clamshell housing for durability in busy environments
• External universal power supply for flexible placement

Specifications

• Print technology: Direct Thermal & Thermal Transfer
• Maximum resolution: 203 x 203 DPI
• Maximum print width: 108 mm
• Maximum print length: 2794 mm
• Print speed: 152.4 mm/sec
• Connectivity: USB 2.0, RS-232 (optional), Ethernet (optional), USB Host
• Printer language: TSPL-EZD
• RAM: 16 MB SDRAM; Flash: 8 MB
• Media types: Continuous, die-cut, black mark, fan-fold, notched
• Max media roll diameter: 127 mm
• Ribbon length: 300 m; ribbon width: 40–110 mm
• Sensors: Gap, black mark, ribbon end, head open
• Power supply: External universal switching power supply
• OS compatibility: Windows, Linux, Mac, Android, iOS (via SDK)
• Display: Status LED indicators

Tips

For best results, use high-quality thermal transfer ribbons when printing labels that must withstand harsh conditions. Calibrate the media sensors after changing label rolls to ensure accurate positioning. Keep the printhead clean with isopropyl alcohol to extend its life. If you need network printing, consider the Ethernet option for easy sharing across your team.
