Vertiv High-Resolution VM CAC USB 2.0 HS IQ-module

The Vertiv High-Resolution VM CAC USB 2.0 HS IQ Module is a compact KVM extender module designed to enhance your KVM extension system with high-resolution video, USB 2.0 high-speed connectivity, and integrated smart card reader support. This module is compatible with Black Box KVX Series KVM Extenders, providing a seamless and secure extension solution for demanding environments.

Advantages

This module delivers exceptional video quality with support for resolutions up to 1920 x 1200 @ 60 Hz (WUXGA) via DVI-I interface. It features four USB 2.0 Type A ports for connecting peripherals and an integrated Common Access Card (CAC) reader for secure authentication. The metal housing ensures durability, and LED indicators provide clear status feedback.

Suitable for

• Data centers and server rooms requiring secure KVM extension
• Government and military facilities using CAC authentication
• Broadcast and control room environments
• Any application needing high-resolution video and USB 2.0 extension

Key specifications

• Product Type: KVM Extender Module
• Video Input: 1 x DVI-I (supports DVI-D and VGA with adapter)
• Maximum Resolution: 1920 x 1200 @ 60 Hz
• USB Standard: USB 2.0 High Speed
• USB Ports: 4 x USB Type A (peripheral), 1 x USB Type B (host)
• Smart Card Reader: Integrated CAC Reader
• Audio: 1 x 3.5mm Speaker Out, 1 x 3.5mm Mic In
• Compatibility: Black Box KVX Series KVM Extenders
• Power Source: Powered by KVM Extender Unit
• Form Factor: Compact Module
• Housing Material: Metal
• Color: Black
• Indicators: LED Status Indicators

Recommendations

For optimal performance, pair this module with compatible Black Box KVX Series extenders. Ensure your system supports the required video and USB standards to fully leverage the module's capabilities.
