Voeding MEAN WELL SPAN02C-15 2 W 15 V 36-75 V

The MEAN WELL SPAN02C-15 is a PCB-mount DC-DC converter designed for compact power conversion on printed circuit boards. It accepts a wide input range of 36–75 Vdc and delivers a single regulated 15 Vdc output at up to 0.134 A (2 W). The module comes in a SIP through-hole package and is RoHS compliant, suitable for projects and equipment requiring a small, board-mounted isolated power source.

Advantages

The SPAN02C-15 provides a stable 15 V output across a broad input voltage range, reducing the need for additional regulation. Its compact SIP through-hole form factor simplifies PCB assembly and mechanical mounting. Low output power and efficient conversion make it suitable for low-power circuits while meeting RoHS environmental requirements.

Suitable for

• Low-power embedded systems and control boards
• Signal conditioning and sensor modules
• Industrial and communication equipment requiring isolated board-mounted power

Key specifications

• Brand: mean well
• Model / MPN: SPAN02C-15
• Input voltage: 36–75 Vdc
• Output voltage: 15 Vdc
• Output current: 0.134 A
• Output power: 2 W
• Package: SIP through-hole (PCB mount)
• Compliance: RoHS

How to use

Mount the SPAN02C-15 into the designated SIP footprint on the PCB and solder the through-hole pins according to the board layout. Apply an input voltage within 36–75 Vdc to the input pins and verify the output on the 15 V output pin. Observe correct polarity and follow the manufacturer’s connection diagram. Provide adequate spacing and thermal considerations on the PCB for reliable operation.

Recommendations

Use the converter within its rated input and output limits, include appropriate input filtering and transient protection on the supply line, and follow PCB layout guidelines for grounding and clearance to ensure stable performance and electrical safety.
