Voltage 12V 0,83A 10W IP67 hermetische schakelvoeding voor aftakdoos 50mm

The Voltage VEC12010 is a compact, hermetic switching power supply designed for installation in junction boxes. With an output of 12V DC and 0.83A (10W), it provides reliable power for LED lighting, automation systems, and other low-voltage applications. Its IP67 rating ensures protection against dust and water ingress, making it suitable for outdoor and harsh environments.

Advantages

Fully potted and sealed housing for moisture and dust resistance. Passive cooling ensures silent operation and long lifespan. Built-in protections against overload, short circuit, over voltage, and over temperature. High efficiency >80% reduces energy waste.

Suitable for

• LED strip lighting and modules
• Home automation and smart devices
• Security cameras and access control
• Industrial sensors and controllers
• Outdoor signage and landscape lighting

Key specifications

• Input: 100-240V AC, 50/60Hz
• Output: 12V DC, 0.83A, 10W
• Protection: Overload, Short Circuit, Over Voltage, Over Temperature
• IP Rating: IP67
• Housing Material: High-grade ABS Plastic
• Output Connection: Bare Wire Leads
• Operating Temperature: -20°C to +50°C
• Dimensions: 50mm diameter (approx.)

Recommendations

Ensure proper wiring and observe polarity. For outdoor use, seal cable entry points to maintain IP67 integrity. Not suitable for direct connection to high-power devices exceeding 10W.
