VOLTAGE Desktop-schakelvoeding 12V 2A 24W 5.5mm/2.1mm voor CCTV

The VOLTAGE VED12020 is a high-quality desktop switching power supply designed for CCTV systems, LED lighting, and general electronics. It delivers a stable 12V DC output at 2A (24W) with a standard 5.5mm/2.1mm barrel connector, center positive polarity. This adapter is built with safety protections including over voltage, over current, and short circuit protection, and meets Energy Efficiency Level VI standards.

Advantages

Reliable and efficient power conversion with wide input voltage range (100-240V AC). Compact desktop form factor with 1.2m output cable. CE and RoHS certified for safety and environmental compliance.

Suitable for

• CCTV cameras and DVRs
• LED strip lighting
• Routers, switches, and networking equipment
• General 12V DC powered devices

Key specifications

• Input: 100-240V AC, 50/60Hz
• Output: 12V DC, 2A, 24W
• DC plug: 5.5mm outer diameter, 2.1mm inner diameter, center positive
• Input connector: C8 (figure 8) – AC cable not included
• Output cable length: 1.2 meters
• Protections: OVP, OCP, SCP
• Efficiency Level: VI
• Operating temperature: 0°C to 40°C

Recommendations

Ensure your device requires 12V DC and 2A or less. The plug size is 5.5mm/2.1mm; verify compatibility. Use only with indoor applications.
