VOLTAGE Desktop-voeding 12V 1A 12W 5,5mm/2,1mm voor CCTV

The VOLTAGE VED12010 is a reliable desktop AC/DC power adapter designed for CCTV systems, LED lighting, routers, and general electronics. It delivers a stable 12V DC output at 1A (12W) with a standard 5.5mm/2.1mm barrel plug, center positive polarity. Built with safety and durability in mind, it features overload, short circuit, and overvoltage protection, making it a trusted choice for continuous operation.

Advantages

This power supply offers a compact desktop form factor with an IEC C8 (Figure-8) input connector, allowing easy replacement of the AC cable. The 1.2-meter DC cable provides flexibility in placement. Its robust ABS plastic housing ensures long-lasting performance, while CE and RoHS certifications guarantee compliance with European safety and environmental standards.

Suitable for

• CCTV cameras and DVRs
• LED strip lights and modules
• Routers and networking equipment
• General 12V DC electronics

Key specifications

• Input: AC 100-240V, 50/60Hz
• Output: 12V DC, 1A, 12W
• DC connector: 5.5mm outer diameter, 2.1mm inner diameter, center positive
• AC connector: IEC C8 (Figure-8)
• DC cable length: 1.2 meters
• Protections: Overload, short circuit, overvoltage
• Housing: ABS plastic, black
• Operating temperature: 0°C to 40°C
• Certifications: CE, RoHS

Recommendations

For optimal performance, ensure the connected device does not exceed 12W total power. This adapter is not suitable for outdoor use unless placed in a weatherproof enclosure. Always verify polarity before connection.
