Wagner design yourself zware zwenkwiel RO 7935 rood 75 mm 100 kg 4793501

Heavy-duty swivel castor with a 75 mm red thermoplastic rubber wheel, engineered for loads up to 100 kg per castor. The galvanized steel housing and plate mounting provide corrosion resistance and secure attachment for demanding applications.

Advantages

The soft tread (85° Shore A) protects sensitive floors like parquet and laminate, while the plain bearing ensures smooth swivelling. The galvanized steel construction resists corrosion, making it suitable for humid or outdoor environments.

Suitable for

• Heavy-duty furniture and transport equipment
• Display stands and mobile workstations
• Floors requiring gentle, non-marking wheels

Key specifications

• Wheel diameter: 75 mm
• Load capacity: 100 kg per castor
• Wheel material: Thermoplastic Rubber (TPR), red
• Housing: Galvanized steel
• Bearing: Plain bearing
• Mounting plate: 60 x 60 mm, hole spacing 48 x 48 mm
• Overall height: 100 mm
• Swivel radius: 60 mm
• Temperature range: -20°C to +60°C

Recommendations

Ideal for applications requiring high load capacity and floor protection. Combine four castors for a total load of 400 kg.
