Weidmüller adereindhuls, geïsoleerd, 70 mm², blauw, 192 A, 10 stuks

The Weidmüller 9512420000 is a high-quality insulated wire end ferrule designed for secure and reliable crimp connections in industrial electrical installations. With a conductor cross-section of 70 mm² and a rated current of 192 A, this ferrule ensures optimal conductivity and durability. The blue insulation sleeve provides clear color coding for easy identification, while the tin-plated electrolytic copper (E-Cu) ferrule body guarantees excellent corrosion resistance and long-term performance.

Advantages

This wire end ferrule offers several benefits: it prevents fraying of stranded wires, ensures a gas-tight connection after crimping, and reduces contact resistance. The polypropylene insulation provides high mechanical strength and thermal stability, making it suitable for demanding environments. Additionally, the ferrule is RoHS compliant and halogen-free, supporting eco-friendly installations.

Suitable for

• Industrial control panels and switchgear
• Automation systems and machinery
• Power distribution and electrical cabinets
• Railway and transportation applications
• Renewable energy systems (solar, wind)

Key specifications

• Product Type: Wire End Ferrule, Insulated
• Conductor Cross-section: 70 mm²
• Rated Current: 192 A
• Color: Blue
• Ferrule Material: E-Cu (Electrolytic Copper), tin-plated
• Insulation Material: Polypropylene (PP)
• Crimp Length: 25 mm
• Insulation Sleeve Length: 25 mm
• Total Length: 50 mm
• Outer Diameter (Insulation): 12.5 mm
• Outer Diameter (Conductor Sleeve): 10.5 mm
• Temperature Range: -40 °C to +105 °C
• Standards/Approvals: DIN 46228 Part 4, UL, CSA
• Packaging Quantity: 10 pieces
• Connection Type: Crimp
• RoHS Compliant: Yes
• Halogen-free: Yes

Recommendations

For optimal performance, use with a suitable crimping tool designed for 70 mm² ferrules. Ensure proper stripping length and crimp force to achieve a reliable connection. Always follow manufacturer guidelines and applicable standards.
