Wiha 47210 Type 2 meetadapter

Electrical installers and test engineers use the Wiha 47210 Type 2 Measuring Adapter to safely connect test instruments to live installations during verification and troubleshooting. The adapter provides a reliable link between a 4 mm safety banana socket and a test pin, enabling precise measurements in distribution panels and industrial equipment.

Key specifications

• Adapter series: Type 2
• Rated voltage: 1000 V
• Rated current: 1 A
• Input connection: 4 mm safety banana socket
• Output connection: test pin / probe tip
• Insulation: double insulated
• Housing material: polyamide (PA)
• Contact material: brass, nickel-plated
• Colour: black
• Quantity per pack: 1 piece

Why choose it

The adapter is built for safe electrical testing, with double insulation and a robust polyamide housing that withstands daily use. Its nickel-plated brass contacts ensure low resistance and long-term reliability, while the compact design fits easily into tool bags and test kits.

Ideal use cases

• Verifying voltage and continuity in electrical installations
• Connecting multimeters or testers to measurement points
• Testing in control cabinets and distribution boards

Good to know

The adapter is designed for use in dry environments and has a pollution degree of 2. It operates within a temperature range of -15°C to +40°C.
