XLR-stekker ShiverPeaks BS55002-G groen – 3-polige mannelijke audioconnector

The ShiverPeaks BS55002-G is a 3-pin XLR male audio connector finished in green, created for balanced microphone and line-level connections. It provides the standard XLR interface used for professional audio signal transfer and is suitable for integration into stage, studio, and broadcast cabling. The connector is intended for wiring to cables and installing into patch panels, stage boxes, or custom audio housings where a robust male XLR termination is required.

Advantages

This 3-pin male XLR connector delivers a stable, low-noise connection for balanced audio lines and is built to meet common professional audio wiring practices. The green finish offers clear visual identification in multi-channel installations and cabling systems. The connector's construction supports secure mating with standard female XLR connectors and is compatible with solder or crimp wiring methods depending on the cable and application.

Suitable for

• Balanced microphone connections on stage and in studios
• Line-level signal patching in broadcast and live-sound setups
• Custom cable assemblies, patch panels, and stage boxes
• Repair or replacement of male XLR terminations

Key specifications

• Connector type: 3-pin male XLR
• Finish: green
• Contact configuration: three contacts for balanced audio (pin 1: ground, pin 2: hot, pin 3: cold)
• Termination: suitable for solder or crimp wiring depending on variant and cable
• Application: microphone and line-level balanced audio

How to use

Strip the audio cable to expose the conductors and prepare the shield, following standard wiring conventions for balanced audio. Solder or crimp the cable conductors to the corresponding pins: pin 1 to shield/ground, pin 2 to positive (hot), and pin 3 to negative (cold). Assemble the connector housing and secure the cable clamp or strain relief to prevent mechanical stress on the terminations. Test continuity and polarity with a multimeter or cable tester before placing the cable into service.

Recommendations

Use the green finish for channel or function identification in multi-cable looms. Choose solder or crimp termination based on cable type and installer preference; ensure strain relief is properly engaged to avoid intermittent connections. Verify polarity and shield continuity after assembly to maintain low-noise balanced operation.
