AdderLink INFINITY ALIF2112T dual head dual link KVM over IP-transmitter

The AdderLink INFINITY ALIF2112T is a high-performance KVM over IP transmitter designed for professional AV and IT environments. It enables the extension of dual-head DVI video, USB 2.0, audio, and serial signals over standard Gigabit Ethernet networks with ultra-low latency and pixel-perfect video quality. This 1U half-width rack-mountable unit is ideal for control rooms, broadcast studios, and secure government installations where reliability and security are paramount.

Advantages

With support for dual DVI-I inputs (digital only) at resolutions up to 1920x1200 per head, the ALIF2112T delivers crisp, lossless video. The integrated USB 2.0 hub allows seamless connection of peripherals, while dedicated audio and serial ports enable full remote workstation control. Advanced security features including AES 128-bit encryption and RSA 2048-bit authentication ensure data integrity. Redundant dual 12V DC power inputs provide fail-safe operation.

Suitable for

• Control room operators requiring real-time KVM extension
• Broadcast and post-production studios with dual-monitor setups
• Secure government and military facilities
• Industrial environments needing remote equipment access

Key specifications

• Product Type: KVM over IP Transmitter
• Video Inputs: 2 x DVI-I (digital only)
• Max Video Resolution: 1920 x 1200 @ 60Hz per head
• USB Host Port: 1 x USB 2.0 Type B
• USB Peripheral Ports: 4 x USB 2.0 Type A
• Audio Ports: 1 x 3.5mm Line In, 1 x 3.5mm Line Out, 1 x 3.5mm Mic In
• Serial Port: 1 x RS232 (DB9)
• Network Ports: 2 x RJ45 Gigabit Ethernet (10/100/1000 Mbps)
• Network Features: Link Aggregation, Network Redundancy
• KVM over IP Technology: AdderLink INFINITY
• Latency: Ultra-low, typically <5ms
• Video Compression: Lossless (pixel-perfect)
• Security: AES 128-bit encryption, RSA 2048-bit authentication
• Form Factor: 1U Rack-mountable (half-width)
• Power Input: Dual 12V DC (redundant)
• Management Interface: Web interface, CLI
• OS Compatibility: Windows, macOS, Linux, Sun Solaris
• Operating Temperature: 0 to 40°C (32 to 104°F)
• Chassis Material: Steel

Recommendations

For optimal performance, pair with a compatible AdderLink INFINITY receiver and use Cat6 or better cabling. Ensure network switches support jumbo frames and IGMP snooping for best results.
