Akyga EN2060-6-F eenfasig EMC-netfilter 6 A, 120–250 V AC, 50/60 Hz, 6,3 mm aansluitingen

The Akyga EN2060-6-F is a single-phase EMI filter designed to suppress electromagnetic interference in equipment supplied with up to 6 A. It is suitable for automation systems, lighting installations and measurement equipment where voltage stability and electronic circuit protection are a priority. The filter features a metal housing for effective interference shielding and durability.

Key features

• Suppresses electromagnetic interference
• Metal housing for effective shielding and durability
• 6.3 mm connectors for quick installation
• Compact form factor

Specifications

• Brand: Akyga
• MPN: EN2060-6-F
• Product type: EMI Filter
• Filter type: Anti-interference
• Maximum working current: 6 A
• Leads: 6.3 mm connectors
• Leakage current: 0.43 mA @120 VAC 60 Hz, 0.74 mA @250 VAC 50 Hz
• Number of poles: 2
• Material: Metal
• Temperature range: -25°C to +100°C
• Product size (L x W x H): 73 x 45 x 29 mm
• CE compatibility: Yes
• RoHS compatibility: Yes
• REACH compatibility: Yes
• EAN code: 5901720138712
