ALLNET 7m SFP+ Direct Attach Copper-kabel 10 Gbps passief 24 AWG zwart

The ALLNET 7m SFP+ Direct Attach Copper (DAC) Cable is a high-performance, passive twinaxial cable designed for 10 Gigabit Ethernet connections in data centers and enterprise networks. It provides a cost-effective, low-power solution for short-range interconnects between switches, servers, and storage devices.

Advantages

This DAC cable offers reliable 10 Gbps data transfer with ultra-low power consumption (<0.1 W), eliminating the need for separate transceivers. Its passive design ensures zero latency and easy hot-swappable installation. The 24 AWG construction and PVC jacket provide durability and flexibility for cable management.

Suitable for

• Data center server-to-switch connections
• Storage Area Networks (SAN)
• High-performance computing clusters
• Enterprise network top-of-rack switching

Key specifications

• Data Transfer Rate: 10 Gbps
• Cable Type: Direct Attach Copper (DAC), Passive
• Connector Type: SFP+ to SFP+
• Cable Length: 7 meters
• Wire Gauge: 24 AWG
• Impedance: 100 Ohm
• Jacket Material: PVC
• Cable Colour: Black
• Compliance: SFF-8431, SFF-8432, MSA Compliant
• Operating Temperature: 0 - 70 °C
• Storage Temperature: -40 - 85 °C
• Supply Voltage: 3.3 V
• Hot-Swappable: Yes

Recommendations

For optimal performance, ensure both connected devices support SFP+ 10GBASE-CR standards. This cable is ideal for rack distances up to 7 meters within the same or adjacent racks.
