Bachmann IT PDU Basic 1U Rackmount PDU - 8x C13 stopcontacten, 16A, 230V, 1,8m kabel, zwart

The Bachmann IT PDU Basic is a reliable and robust power distribution unit designed for professional IT environments. This 1U rackmount PDU provides 8 IEC C13 outlets, making it ideal for distributing power to servers, network switches, and other critical equipment in data centers and server rooms. With a maximum current rating of 16A and an input voltage of 230V, it delivers up to 3.68 kW of power. The PDU features a 1.8m input cable with an IEC C14 plug and is constructed with a durable aluminium housing in black. It is a basic (non-metered, non-switched) unit, ensuring simple and cost-effective power distribution without unnecessary complexity.

Advantages

This PDU offers a straightforward solution for power distribution, with no metering or switching features that could introduce points of failure. The aluminium housing provides excellent durability and heat dissipation. The 1U form factor saves valuable rack space, and the rear cable entry helps with cable management. The unit is CE and RoHS certified, ensuring compliance with European standards.

Suitable for

• Data centers and server rooms requiring reliable power distribution
• Rack-mounted IT equipment such as servers, switches, and patch panels
• Applications where basic, non-metered power distribution is sufficient
• Environments requiring a compact 1U solution with 8 C13 outlets

Key specifications

• PDU Type: Basic (Non-metered, Non-switched)
• Mounting: 1U Horizontal Rackmount
• Input Connector: 1 x IEC 60320 C14
• Output Connectors: 8 x IEC 60320 C13
• Nominal Input Voltage: AC 230 V
• Maximum Input Current: 16 A
• Power Rating: 3.68 kW (3680 W)
• Input Cable Length: 1.8 m
• Frequency: 50/60 Hz
• Number of Phases: Single-phase
• Housing Material: Aluminium
• Color: Black
• Operating Temperature: 0 - 45 °C
• Storage Temperature: -20 - 60 °C
• Humidity: 10 - 90% RH (non-condensing)
• Certifications: CE, RoHS
• Internal Wiring: 1.5 mm²

Recommendations

For optimal performance, ensure that the total connected load does not exceed 16A. Use appropriate power cords with C13 connectors for your equipment. This PDU is best suited for environments where power monitoring and remote switching are not required.
