Bachmann stekkerdoos ingangsstekker - ingang, GST18i3 stekkeringang

The Bachmann 912.023 is a high-quality power strip input connector designed for reliable power distribution in industrial and commercial applications. Featuring a Wieland GST18i3 male inlet, this component ensures secure and efficient power input for power strips, distribution units, and various devices. Manufactured by Bachmann, a trusted brand in electrical connectivity, this connector offers robust construction and compliance with VDE and CE standards.

Advantages

This connector provides a standardized and safe power input solution with screw terminals for easy installation. Its snap-in or panel mount design allows for flexible integration into enclosures and power strips. The polyamide housing with UL94 V-0 flammability rating ensures durability and fire safety. With a rated voltage of 250V AC and current of 16A, it supports a wide range of power requirements.

Suitable for

• Power strips and distribution units
• Industrial equipment and machinery
• Commercial power distribution systems
• Panel-mounted power input applications

Key specifications

• Connector Type: Wieland GST18i3
• Number of Poles: 3-pole (L, N, PE)
• Connector Gender: Male (Device Inlet)
• Rated Voltage: 250V AC
• Rated Current: 16A
• Termination Type: Screw Terminals
• Mounting Type: Snap-in / Panel Mount
• Housing Material: Polyamide (PA)
• Color: Black
• Ingress Protection (IP) Rating: IP20 (unmated), IP40 (mated with appropriate connector)
• Operating Temperature: -5°C to +40°C
• Flammability Rating: UL94 V-0
• Standards Compliance: VDE, CE

Recommendations

For optimal performance, ensure proper mating with a compatible GST18i3 female connector. This component is ideal for building custom power distribution solutions where a reliable and standardized input is required.
