BlueOptics HPE M-Series R5Z83A QSFP56-transceiver, 200GBASE-SR4, multimode vezel, 850nm, 100 meter, MPO/MTP, DDM

The BlueOptics R5Z83A-BO is a high-performance QSFP56 transceiver designed for compatibility with HPE M-Series networking equipment. It delivers 200 Gbps data rate over multimode fiber using 200GBASE-SR4 standard, ideal for data center interconnects and high-performance computing environments.

Advantages

This transceiver offers reliable, hot-swappable connectivity with low power consumption under 4.5W. It supports Digital Diagnostic Monitoring (DDM) for real-time performance tracking, ensuring optimal network uptime. The MPO/MTP-12 connector simplifies high-density cabling, reducing deployment complexity.

Suitable for

• Data center interconnects requiring high bandwidth
• High-performance computing clusters
• Enterprise network upgrades to 200G Ethernet
• HPE M-Series switch and router installations

Key specifications

• Form Factor: QSFP56
• Data Rate: 200 Gbps (4x 50Gbps PAM4 lanes)
• Optical Standard: 200GBASE-SR4
• Wavelength: 850 nm
• Fiber Type: Multimode (OM4)
• Max Reach: 100 meters
• Connector: MPO/MTP-12
• DDM/DOM: Yes
• Operating Temperature: 0°C to +70°C
• Power Consumption: < 4.5 W
• Hot-Swappable: Yes
• Certifications: CE, FCC, RoHS

Recommendations

For optimal performance, use with OM4 multimode fiber and ensure your HPE M-Series equipment supports QSFP56 modules. This transceiver is a cost-effective alternative to the original HPE R5Z83A, offering identical specifications and full compatibility.
