BOPLA 43430004.MT1 universele behuizing, ABS, lichtgrijs, 120 x 65 x 40 mm, IP65

The BOPLA 43430004.MT1 is a light grey universal enclosure moulded from ABS, sized 120 x 65 x 40 mm, with a recessed lid that accepts membrane keypads or labels. Its IP65 protection and polyurethane gasket make it suitable for housing electronics in damp or dusty environments, while the four stainless steel lid screws provide secure closure.

Highlights

• Material: ABS (Acrylonitrile Butadiene Styrene), light grey (RAL 7035)
• External dimensions: 120 mm width, 65 mm depth, 40 mm height
• Protection class: IP65 (dust-tight and protected against water jets)
• Lid fastening: 4x stainless steel screws
• Gasket material: Polyurethane (PUR)
• Operating temperature range: -40 °C to +80 °C
• Flammability rating: UL 94 HB
• Impact resistance: IK07
• Internal mounting bosses for PCBs or components; wall mounting possible
• Chemical resistance: good against aqueous acids, alkalis, salt solutions
• Fully insulated, halogen-free, RoHS compliant
• Number of components: 2 (base, lid)
• Wall thickness: approx. 2.5 mm

In daily use

The enclosure's recessed lid allows a membrane keypad or label to be applied flush with the surface, protecting the interface while maintaining a clean appearance. The internal bosses simplify PCB mounting, and the PUR gasket ensures a reliable seal when the lid is screwed down.

Full specifications

• Brand: BOPLA
• Model: 43430004.MT1
• MPN: 43430004.MT1
• EAN: 4016138524888
• Product type: Universal enclosure
• Material: ABS
• Colour: Light grey
• Width: 120 mm
• Depth: 65 mm
• Height: 40 mm
• Protection class: IP65
• Gasket material: Polyurethane (PUR)
• Operating temperature range: -40 °C to +80 °C
• Flammability rating: UL 94 HB
• Impact resistance: IK07
• Halogen-free: Yes
• RoHS compliant: Yes

Final note

The BOPLA 43430004.MT1 offers a robust, sealed housing for electronics in industrial or outdoor applications, with a design that supports both membrane keypads and internal component mounting.
