Busch-Jaeger Busch-Wächter 180 UP sensor Comfort II, inbouw bewegingsmelder, alpinwit

Unlike conventional motion detectors that merely switch lights on and off, the Busch-Jaeger 6127/02-884 Sensor Komfort II brings intelligent presence detection to your flush-mounted installation. This sensor unit from the Busch-Wächter 180 UP series combines a wide 180° detection angle with advanced features such as creep zone protection, teach-in function, and remote control capability, making it a versatile choice for both residential and commercial spaces.

Highlights

• 180° detection angle with 104 detection zones and 6 detection levels for precise coverage
• Frontal detection range up to 12 m and lateral range up to 8 m on each side
• Adjustable brightness threshold from 5 to 1000 lux and time delay from 10 seconds to 30 minutes
• Creep zone detection ensures reliable triggering even directly beneath the sensor
• Supports short-term ON, test mode, and teach-in function for customized operation
• Compatible with optional IR remote control for convenient adjustments
• Flush-mounted design in alpine white blends seamlessly with modern interiors

In daily use

Installed at a recommended height of 0.8 to 1.2 meters, this sensor unit works with a Busch-Jaeger flush-mounted insert (e.g., 6812 U-101 or 6814 U-101) to control lighting based on movement and ambient light. The presence detection feature keeps lights on while someone remains in the room, even without significant motion, enhancing comfort and energy efficiency. The teach-in function allows you to set the current brightness level as the threshold, simplifying calibration. For added convenience, the sensor can be operated via an optional IR remote, enabling adjustments without accessing the unit directly.

Full specifications

• Product type: Sensor unit for motion/presence detection
• Series: Busch-Wächter 180 UP Sensor Komfort II
• Mounting type: Flush-mounted (UP)
• Detection angle: 180°
• Recommended mounting height: 0.8 - 1.2 m
• Detection range frontal: approx. 12 m
• Detection range lateral: approx. 8 m to each side
• Creep zone: Yes
• Brightness threshold adjustable: approx. 5 - 1000 lux
• Time delay adjustable: approx. 10 s - 30 min
• Colour: Alpine white
• Material: Thermoplastic (PC)
• IP rating: IP20
• Operating temperature: 0 °C to +45 °C
• Number of detection levels: 6
• Number of detection zones: 104
• Compatibility: Requires Busch-Jaeger flush-mounted insert (e.g., 6812 U-101, 6814 U-101)
• Special features: Presence detection, short-term ON, test mode, teach-in function, remote control capable

Final note

The Busch-Jaeger 6127/02-884 Sensor Komfort II is not just a motion detector; it's a smart presence sensor that adapts to your environment, ensuring lights are on when needed and off when not, with the flexibility of remote control and advanced programming.
