Busch-Jaeger ruimtetemperatuurregelaar 10-voudig, wit SBR-F-10.0.11-84 (2CKA006220A0889)

This Busch-Jaeger room temperature controller offers a straightforward 2-point control for heating or cooling systems, with a 10 A switching capacity for resistive loads. Unlike digital thermostats, it uses a rotary knob for direct, tool-free temperature adjustment and includes a thermal feedback mechanism for stable regulation.

Highlights

• Flush-mounted design for seamless integration into standard wall boxes
• Manual rotary knob with temperature range +5 °C to +30 °C
• Switching output: 1 normally open (heating) or 1 normally closed (cooling)
• Thermal feedback and ON/OFF switch for precise control
• Control LED indicates heating or cooling status
• Temperature reduction input for energy-saving set-back

In daily use

The controller is suitable for heating and cooling systems, including floor heating. It operates on 230 V AC, 50 Hz, and handles up to 10 A resistive or 2 A inductive loads. No display is needed—the rotary knob provides tactile, reliable adjustment. A separate cover frame from the future® linear, carat®, solo®, Busch-axcent®, or alpha® series is required for a finished look.

Full specifications

• Product type: Room Temperature Controller
• Control type: 2-point (ON/OFF)
• Mounting type: Flush-mounted
• Colour: Alpine White
• Supply voltage: 230 V AC
• Frequency: 50 Hz
• Switching current (resistive): max. 10 A
• Switching current (inductive): max. 2 A
• Temperature setting range: +5 °C to +30 °C
• Output: 1 NO (heating) or 1 NC (cooling)
• Display: No (rotary knob)
• Features: Thermal feedback, ON/OFF switch, temperature reduction input, control LED
• Protection class: IP20
• Suitable for: Heating and cooling systems, floor heating
• Compatibility: Requires separate cover frame (future® linear, carat®, solo®, Busch-axcent®, alpha®)
• Material: Thermoplastic

Final note

A reliable, no-frills room temperature controller for standard flush-mounted installations, with proven thermal feedback and a simple rotary interface.
