DSIT CAT6 netwerkkabel U/UTP 50 m grijs 100% koper (DC-61-500)

With a 250 MHz bandwidth and 100% solid copper conductors, this 50-metre CAT6 cable delivers reliable 10-Gigabit Ethernet performance over shorter runs, making it an excellent backbone for high-speed networks.

Overview

The DSIT DC-61-500 is a bulk CAT6 network installation cable with no connectors, ready for custom termination in structured cabling projects. It contains four twisted pairs of solid 23 AWG bare copper conductors, ensuring excellent conductivity and compliance with TIA/EIA-568-B.2-1. The unshielded design (U/UTP) is ideal for areas with low electromagnetic interference, and the 6.2 mm outer diameter allows easy pulling through conduits and cable trays.

What stands out

• 100% solid copper conductors – no copper-clad aluminium, guaranteeing long-term performance.
• Supports 10GBASE-T up to 55 metres and 1000BASE-T up to 100 metres.
• 250 MHz bandwidth exceeds CAT5e, future-proofing your network.
• PVC jacket with CM flammability rating for general indoor use.
• RoHS and CE compliant for safety and environmental standards.

Technical details

• Category: CAT6
• Shielding: U/UTP (unshielded)
• Length: 50 metres
• Conductor: Solid bare copper, 23 AWG
• Number of pairs: 4
• Impedance: 100 Ohm
• Frequency: 250 MHz
• Outer diameter: approx. 6.2 mm
• Jacket material: PVC
• Operating temperature: -20°C to 60°C
• Compliance: RoHS, CE, TIA/EIA-568-B.2-1

Our verdict

A dependable, high-performance CAT6 cable for professional installers who demand genuine copper and reliable gigabit speeds.
