DSIT DANICOM CAT6A U/UTP 50m flexibele PVC (Fca) netwerk-installatiekabel

Running 10 Gigabit Ethernet over longer distances often means choosing between performance and flexibility. This DSIT DANICOM CAT6A U/UTP cable solves that by combining full 500 MHz bandwidth with a flexible PVC jacket, making it easy to install in tight spaces without sacrificing speed.

Who is it for

Network installers, IT technicians, and system integrators who need a reliable, high-performance cable for indoor horizontal cabling. It’s ideal for offices, data centres, and smart buildings where 10GBASE-T connectivity is required over runs up to 50 metres.

Main features

• Category 6A performance: supports 10 Gigabit Ethernet up to 50 m
• U/UTP construction: unshielded twisted pairs reduce cost and weight while maintaining signal integrity
• Flexible PVC jacket: easy to route through conduits, corners, and cable trays
• Solid bare copper conductors: 23 AWG for consistent performance and PoE support
• Euroclass Fca fire rating: suitable for indoor use in most building areas
• Compliant with ISO/IEC 11801, EN 50173, and TIA/EIA-568-C.2

Specifications

• Cable type: Cat6A U/UTP
• Length: 50 m
• Conductor: solid bare copper, 23 AWG
• Number of pairs: 4 twisted pairs
• Impedance: 100 Ohm
• Frequency: 500 MHz
• Outer diameter: approx. 6.5 mm
• Jacket material: PVC
• Fire rating: Fca
• Application: indoor horizontal cabling

Tips

When installing, avoid sharp bends and excessive pulling force to maintain the cable’s electrical performance. Use proper cable management accessories to keep the run neat and reduce stress on connectors.
