Eaton EVG16/3X1PHAS 6-module 3-fasen-pin-verzamelrail 16A 230/400V 291487

Modular electrical installations often require a reliable way to distribute power across multiple DIN rail devices without complex wiring. The Eaton EVG16/3X1PHAS busbar provides a compact 6-module, 3-phase connection solution for 16 A circuits, simplifying panel assembly and reducing wiring errors.

Who is it for

Electricians and panel builders working with Eaton xPole modular devices such as miniature circuit breakers (MCBs) and residual current devices (RCDs). It suits residential and commercial distribution boards where three-phase power needs to be distributed to multiple single-phase loads.

Main features

• 6-module pin-type busbar for three-phase distribution
• Rated current 16 A, rated voltage 230/400 V AC
• Copper conductor with self-extinguishing thermoplastic insulation
• 18 mm pitch matches standard DIN rail modular devices
• Designed for Eaton xPole series compatibility

Specifications

• Product type: Pin busbar
• Number of poles: 6
• Number of phases: 3 (for 3x1-phase connections)
• Rated current: 16 A
• Rated voltage: 230/400 V AC
• Connection type: Pin type
• Conductor material: Copper
• Insulation material: Self-extinguishing thermoplastic
• Busbar pitch: 18 mm
• Operating temperature: -25 to +50 °C
• Protection degree: IP20 (when installed)
• Certifications: CE, VDE

Tips

Ensure the busbar is used only with compatible Eaton xPole devices to maintain proper contact and safety. Install within an enclosure to achieve the IP20 protection rating. For three-phase distribution, connect the three incoming phases to the appropriate terminals and distribute single-phase loads across the modules.
