Eaton T5B-4-8902/E 4-polige draaischakelaar, 32 A, 690 V AC, zwart/wit 207430

Rotary control switch with 4 poles, rated for 32 A uninterrupted current at 690 V AC. The T5B-4-8902/E provides reliable ON-OFF switching in industrial control circuits, with a black actuator and white front plate marked 0-1.

Advantages

Front IP65 protection suits demanding environments. Screw terminals ensure secure connections. 90° switching angle and 2 positions give clear, simple operation.

Suitable for

• Main switch applications in machine control panels
• Motor disconnection in industrial installations
• Heating and lighting circuit isolation

Key specifications

• Switch type: Rotary control switch / main switch
• Number of poles: 4
• Switching function: ON-OFF (0-1)
• Rated uninterrupted current (Iu): 32 A
• Rated operational voltage (Ue): 690 V AC
• Rated impulse withstand voltage (Uimp): 6 kV
• Rated conditional short-circuit current (Iq): 6 kA
• Degree of protection (front): IP65
• Degree of protection (terminals): IP20
• Mounting: Front mounting, central fixing
• Actuator color: Black
• Front plate color: White with 0-1 inscription
• Switching angle: 90°
• Number of switching positions: 2
• Terminal type: Screw terminals
• Standards: IEC/EN 60947-3
• Ambient operating temperature: -25 to +50 °C
• Series: T5B

Recommendations

Select this switch for compact, high-current control with clear visual status indication and robust front protection.
