EUROLITE LED TMH Bar H240 Moving-Head Beam/Flower 51786057

Lighting designers often struggle to create dynamic, multi-beam effects from a single fixture without cluttering the rig. The EUROLITE LED TMH Bar H240 solves this by combining ten individually controllable 10W RGBW LEDs in a motorized bar that pans 540° and tilts 270°, producing a wide array of beam and flower effects from one compact unit.

Who is it for

This moving-head bar is ideal for mobile DJs, event production companies, clubs, and stage lighting professionals who need versatile, high-impact lighting with minimal setup time. Its pixel-mapping capabilities and pre-programmed shows make it suitable for both novice users and experienced lighting programmers.

Main features

• 10x 10W RGBW 4-in-1 LEDs with individual pixel control for stunning beam and flower effects
• Wide 540° pan and 270° tilt movement for full coverage
• Selectable DMX channel modes: 10, 12, 16, 20, 42, 44, 54, or 56 channels
• Multiple control options: DMX512, sound-to-light, auto mode, and master/slave
• Built-in strobe, dimmer, and pre-programmed shows for instant effects
• LCD display with 4-button operation for easy configuration
• Power and DMX looping via P-Con and 3-pin XLR connectors
• Robust metal and plastic housing with fan cooling for reliable performance
• Includes omega bracket for secure truss mounting

Specifications

• Light source: 10x 10W RGBW LEDs (4-in-1)
• Total power consumption: 120W
• Beam angle: 5°
• Pan range: 540°
• Tilt range: 270°
• DMX channels: 10/12/16/20/42/44/54/56
• Operating voltage: 100-240V AC, 50/60Hz
• IP rating: IP20 (indoor use only)
• Cooling: Fan-cooled
• Connectors: P-Con power in/out, 3-pin XLR DMX in/out
• Housing: Metal and plastic
• Mounting: Omega bracket included

Tips

For best results, use a DMX controller with pixel mapping to create custom chase sequences across the ten LEDs. When using sound-to-light mode, position the fixture away from bass-heavy speakers to avoid unwanted triggering. Always secure the omega bracket properly and use a safety cable when rigging overhead.
