Evolights Lumen Pix Bar 12x3W warmwit LED strip bar

The Evolights Lumen Pix Bar stands apart from typical LED strip bars by pairing a warm 3200K color temperature with a tight 25° beam angle, delivering a focused, tungsten-like wash that flatters skin tones and warm interiors without the harshness of cool-white fixtures. Its slim aluminum housing and convection cooling mean it runs silently, making it equally at home in theaters, galleries, and intimate live stages.

Highlights

• 12x 3W warm white LEDs (36W total) for a rich, incandescent-style glow
• Selectable DMX channel modes (2/3/4/6) for flexible control integration
• Linear electronic dimming 0–100% with variable speed strobe
• Dual adjustable mounting brackets for floor, truss, or wall placement
• 4-button LED display for easy standalone configuration

In daily use

Whether you're washing a cyclorama, accenting architectural details, or creating a warm key light for video, the Lumen Pix Bar delivers consistent output with no fan noise. Its master/slave and sound-active modes allow quick setup without a console, while the 3-pin XLR in/out ensures simple daisy-chaining in larger rigs. The IP20 rating means it's intended for dry, indoor environments, but the robust aluminum alloy body shrugs off the bumps of touring and frequent repositioning.

Full specifications

• Light source: 12x 3W warm white LEDs
• Total LED power: 36W
• Color temperature: 3200K
• Beam angle: 25°
• Control modes: DMX512, Auto, Sound Active, Master/Slave
• DMX channels: 2/3/4/6 (selectable)
• DMX connectors: 3-pin XLR In/Out
• Power consumption: 40W
• Power input: AC 100-240V, 50/60Hz
• Housing material: Aluminum alloy
• IP rating: IP20 (indoor use)
• Dimming: 0-100% linear electronic
• Strobe: variable speed
• Display: 4-button LED digital
• Mounting: dual adjustable brackets
• Cooling: convection
• Operating temperature: -20°C to 40°C

Final note

For lighting designers who need a reliable warm-white linear wash with precise control, the Lumen Pix Bar offers a compact, silent, and road-ready solution that integrates seamlessly into any DMX universe.
