Fujitsu WLAN-antennes (zonder module)

Tri-band 2.4/5/6 GHz coverage with 3 dBi gain and a compact 30 x 5 x 1 mm FPC profile makes this Fujitsu antenna kit a direct drop-in upgrade for Wi-Fi 6E modules in laptops, mini-PCs, and embedded systems. The pair of adhesive-backed antennas with 200 mm MHF4 pigtails delivers full 802.11ax performance across all modern bands, including the 6 GHz spectrum for low-latency, high-throughput connections.

Overview

Engineered for internal installation, this kit includes two flexible printed circuit (FPC) antennas with pre-attached coaxial cables terminated in IPEX MHF4 connectors. Designed to replace or upgrade the wireless antennas in Fujitsu systems equipped with MHF4-compatible Wi-Fi modules such as Intel AX200 or AX210 series, it ensures optimal signal reception and transmission for Wi-Fi 6E networks. The antennas feature a linear polarization, 50 Ohm impedance, and a VSWR below 2.0 for reliable performance across the entire supported frequency range.

What stands out

• Tri-band support: 2.4 GHz, 5 GHz, and 6 GHz for Wi-Fi 6E compatibility
• Compact FPC design (30 x 5 x 1 mm) fits easily inside tight chassis spaces
• Adhesive backing allows secure, tool-free mounting on internal surfaces
• 200 mm cable length provides flexibility in antenna placement
• IPEX MHF4 connectors ensure compatibility with modern Wi-Fi modules
• RoHS compliant and built with durable FPC and coaxial cable materials

Technical details

• Antenna type: Internal FPC (Flexible Printed Circuit)
• Frequency bands: 2.4 GHz, 5 GHz, 6 GHz
• Wi-Fi standards: IEEE 802.11a/b/g/n/ac/ax (Wi-Fi 6E)
• Gain: 3 dBi
• Connector: IPEX MHF4 (U.FL compatible)
• Cable length: 200 mm (approx. 7.9 inches)
• Impedance: 50 Ohm
• Polarization: Linear
• VSWR: < 2.0
• Operating temperature: -20°C to 65°C
• Material: FPC with coaxial cable
• Colour: Black
• Number of antennas included: 2
• Mounting method: Adhesive backing
• Environmental compliance: RoHS

Our verdict

For anyone upgrading a Fujitsu system to Wi-Fi 6E, this antenna kit provides the necessary tri-band coverage and reliable connectivity in a space-saving form factor. The adhesive mounting and generous cable length simplify installation, while the MHF4 connectors ensure broad module compatibility. A solid choice for maintaining peak wireless performance.
