GoodConnections LW-U815LC4 glasvezel-patchkabel, OM4 duplex LC/LC Uniboot, LSZH, 15 m, aqua

The GoodConnections LW-U815LC4 is a high-performance fiber optic patch cable designed for demanding network environments. Featuring OM4 multimode fiber with 50/125 µm core/cladding, this duplex cable delivers exceptional bandwidth and reliability for data centers, SANs, and high-speed LANs. The LC Uniboot connectors with exchangeable polarity and push-pull release tab simplify installation and polarity management. The LSZH (Low Smoke Zero Halogen) jacket ensures safety in confined spaces, while the aqua color indicates OM4 performance.

Advantages

Optimized for 40/100 GbE applications with 4700 MHz-km bandwidth at 850nm. Reversible polarity eliminates the need for crossover cables. Uniboot design reduces cable congestion and improves airflow. LSZH jacket minimizes toxic smoke in case of fire.

Suitable for

• Data centers and server rooms
• Storage Area Networks (SANs)
• High-speed local area networks (LANs)
• Telecommunications and enterprise cabling

Key specifications

• Cable type: Fiber Optic Patch Cable, Multimode OM4
• Connectors: LC Uniboot to LC Uniboot, Duplex
• Length: 15 meters
• Jacket: LSZH (Low Smoke Zero Halogen)
• Polarity: Exchangeable/Reversible
• Insertion loss: ≤ 0.3 dB typical
• Return loss: ≥ 30 dB typical
• Operating temperature: -20°C to +70°C
• Compliance: RoHS, REACH

Recommendations

For optimal performance, use with OM4-compatible transceivers and ensure clean connector end-faces. Suitable for backbone and horizontal cabling in high-speed networks.
