Grandstream GWN7672L Wi-Fi 6E tri-band in-wall access point

Hotels, offices, and multi-dwelling units often struggle with weak Wi-Fi signals in individual rooms. The Grandstream GWN7672L mounts directly into a standard US or EU junction box, replacing the wall plate and delivering high-speed tri-band Wi-Fi 6E connectivity right where it's needed. It operates simultaneously on 2.4 GHz, 5 GHz, and 6 GHz bands, with aggregate data rates up to 3.55 Gbps, ensuring smooth performance for dozens of concurrent clients.

Key specifications

• Wi-Fi Standard: IEEE 802.11 a/b/g/n/ac/ax (Wi-Fi 6E)
• Tri-Band Operation: 2.4 GHz, 5 GHz, and 6 GHz
• MIMO: 2x2:2 MU-MIMO on all three radios
• Maximum Aggregate Throughput: 3.55 Gbps
• Antenna: 3 internal omnidirectional antennas (2.4 GHz: 3.5 dBi, 5 GHz: 4.5 dBi, 6 GHz: 4.5 dBi)
• Ethernet Port: 1 x 10/100/1000Base-T Gigabit port (PoE/PoE+ in)
• Power Consumption: 12.95W (802.3af/at compliant)
• Concurrent Clients: 256+
• Security: WPA/WPA2/WPA3-PSK, WPA/WPA2/WPA3 Enterprise
• Management: GWN.Cloud, GWN Manager, or embedded controller
• Additional Port: 1 x USB-C
• Wireless Features: OFDMA, TWT, BSS Coloring, Beamforming

Why choose it

The GWN7672L leverages Wi-Fi 6E technology, including the 6 GHz band, to reduce interference and increase capacity. Advanced features like OFDMA, TWT, and BSS Coloring optimize spectrum efficiency, while beamforming enhances signal strength. With support for 256+ clients and robust security options, it's a reliable choice for high-density environments.

Ideal use cases

• Hotel guest rooms and suites
• Office meeting rooms and private offices
• Multi-dwelling units (MDUs) and student housing
• Healthcare facilities and clinics
• Retail spaces requiring discreet APs

Good to know

The GWN7672L is designed for easy installation in standard junction boxes, making it ideal for retrofits. It supports PoE/PoE+ for simplified cabling and can be managed via Grandstream's cloud platform, on-premises manager, or its embedded controller. The USB-C port provides flexibility for future expansions.
