Hager FZ596 communicatieverdeler met 4x Cat6 RJ45-poorten en tv-splitter

The Hager FZ596 is a high-quality communication enclosure designed for residential and small tertiary buildings. It integrates voice, data, and TV distribution in a single compact unit, making it ideal for modern home networking and multimedia installations. The enclosure supports ADSL and fibre optic connections (via modem/ONT) and includes a 1-input/4-output TV splitter for satellite or terrestrial TV distribution.

Advantages

All-in-one solution for data and TV distribution; easy surface or flush mounting; compliant with NF C 15-100 standards; robust ABS plastic construction with IP20 and IK07 protection; includes all necessary modules for quick installation.

Suitable for

• Residential homes requiring structured cabling for internet, phone, and TV
• Small offices or tertiary buildings with limited space
• New builds or renovations needing a central communication point

Key specifications

• Product Type: Communication Enclosure
• VDI Grade: Grade 3 TV
• Number of RJ45 Ports: 4 (Cat6 UTP)
• TV Distribution: Integrated 1-input/4-output splitter
• Mounting Type: Surface or flush (within cabinet)
• Material: ABS Plastic
• Colour: White (RAL 9003)
• Standards Compliance: NF C 15-100
• IP Protection Rating: IP20
• IK Protection Rating: IK07
• Operating Temperature: -5 to 40 °C
• Storage Temperature: -25 to 70 °C
• Included Accessories: 4x RJ45 Cat6 modules, 1x TV splitter, 1x patch panel, 1x DTI module

Recommendations

For optimal performance, use with Hager compatible patch cables and accessories. Ensure proper ventilation and avoid exposure to extreme temperatures.
