HellermannTyton HAT-25MM-PABUX1 krimpkous-assortiment, 100 stuks, 2:1, zwart, 100 mm lengtes 161-60004

Managing multiple wire diameters and needing reliable insulation often means juggling several spools or boxes, which slows down installation and repair work. The HellermannTyton HAT-25MM-PABUX1 assortment solves this by bundling nine common heat shrink tubing sizes in one dispenser box, each piece pre-cut to 100 mm. Made from cross-linked polyolefin with a 2:1 shrink ratio, the black tubing shrinks at +90 °C to form a tight, protective seal around cables, connectors, and splices.

Who is it for

Electricians, panel builders, automotive technicians, and maintenance crews who need quick access to multiple heat shrink sizes without buying full reels of each. The assortment is also suitable for prototyping labs and field service kits where space and organisation matter.

Main features

• Assortment of 9 diameters: 1.6/0.8 mm (20 pcs), 2.4/1.2 mm (20 pcs), 3.2/1.6 mm (20 pcs), 4.8/2.4 mm (10 pcs), 6.4/3.2 mm (10 pcs), 9.5/4.8 mm (10 pcs), 12.7/6.4 mm (5 pcs), 19.1/9.5 mm (3 pcs), 25.4/12.7 mm (2 pcs).
• 2:1 shrink ratio for a secure fit over irregular shapes.
• Cross-linked polyolefin material resists common fluids and abrasion.
• Self-extinguishing flame retardant behaviour.
• Supplied in a dispenser box for easy size selection and storage.

Specifications

• Material: Cross-linked polyolefin
• Shrink ratio: 2:1
• Colour: Black
• Total pieces: 100
• Length per piece: 100 mm
• Minimum shrink temperature: +90 °C
• Operating temperature range: -55 °C to +125 °C
• Dielectric strength: 20 kV/mm
• Tensile strength: 10.4 MPa
• Elongation at break: 200%
• Flame retardant: Yes (self-extinguishing)
• Halogen-free: No
• Approvals/Standards: UL224, CSA, RoHS Compliant

Tips

Use a heat gun set to the recommended shrink temperature and move it evenly around the tubing to avoid scorching. For best results, select a tubing size whose recovered diameter is slightly smaller than the object being covered. Store the dispenser box in a dry location away from direct sunlight to maintain material properties.
