Hikvision DS-3E0508P-O 8-poorts 4-PoE unmanaged switch

The Hikvision DS-3E0508P-O is a reliable and cost-effective unmanaged switch designed for small to medium-sized networks. With 8 Ethernet ports, 4 of which support Power over Ethernet (PoE), it simplifies network deployment by delivering both data and power to devices such as IP cameras, access points, and VoIP phones. This switch is ideal for surveillance systems and office networks where simplicity and performance are key.

Advantages

Easy plug-and-play setup with no configuration required. The fanless design ensures silent operation, making it suitable for noise-sensitive environments. PoE support eliminates the need for separate power cables for connected devices, reducing installation costs and clutter. Compact desktop and wall-mountable design offers flexible placement options.

Suitable for

• Small business networks
• IP surveillance systems
• Wireless access point deployment
• VoIP phone systems
• Home office setups

Key specifications

• 8 x 10/100 Mbps Ethernet ports
• 4 x PoE ports (IEEE 802.3af/at)
• Total PoE budget: 35W, up to 30W per port
• Switching capacity: 1.6 Gbps
• Packet forwarding rate: 1.19 Mpps
• MAC address table: 2K entries
• Jumbo frame support: 1536 bytes
• Power supply: 48 VDC external adapter
• Power consumption: ≤ 38W
• Operating temperature: 0°C to 40°C
• Surge protection: 6 KV
• Fanless, silent operation

Recommendations

For optimal performance, use this switch with Hikvision IP cameras and NVRs. Ensure the total PoE power draw does not exceed 35W. The switch is unmanaged, so it is best for simple networks where advanced features like VLANs are not required.
