IP-camera TC-C34QN 2ENA-28 Spark Series - 4 MP 2,8 mm Tiandy

The Tiandy TC-C34QN 2ENA-28 is a high-performance 4 Megapixel IP camera from the Spark Series, designed for reliable indoor and outdoor surveillance. Featuring a 2.8 mm fixed lens with a 97.6° horizontal field of view, this mini dome camera delivers crisp 2560 x 1440 resolution at 25 fps. With advanced H.265 compression, 120 dB WDR, and built-in IR LEDs for up to 30 m night vision, it ensures clear imaging in challenging lighting conditions. The camera supports DC 12V and PoE (802.3af) power, and is rated IP67 and IK10 for weather and vandal resistance.

Advantages

Exceptional image quality with 4 MP resolution and 120 dB WDR for high-contrast scenes. Reliable night vision up to 30 m. Robust metal housing with IP67 and IK10 ratings ensures durability in harsh environments. Flexible power options via DC 12V or PoE simplify installation. Built-in microphone for audio recording. Supports micro SD card storage up to 512 GB.

Suitable for

• Retail stores and shops
• Office buildings and reception areas
• Warehouses and logistics centers
• Parking lots and building entrances
• Residential outdoor surveillance

Key specifications

• Sensor: 1/2.7" CMOS, 4 MP (2560 x 1440)
• Lens: 2.8 mm fixed, FOV H: 97.6°
• IR Distance: Up to 30 m
• Video Compression: H.265, H.264, M-JPEG
• WDR: 120 dB
• Audio: Built-in microphone
• Storage: Micro SD slot, up to 512 GB
• Network: 1x RJ45 10/100M Ethernet
• Power: DC 12V / PoE (802.3af)
• Ingress Protection: IP67
• Vandal Resistance: IK10
• Operating Temperature: -30°C to 60°C

Recommendations

For optimal performance, use a PoE switch or injector compliant with IEEE 802.3af. Ensure the micro SD card is high endurance for continuous recording. Mount the camera in a location with a clear view of the area of interest, avoiding direct sunlight or extreme reflections.
