JUNG FM-antenne met magneetvoet FM ANT (FMANT)

With a frequency range of 87.5 to 108 MHz and a 50-ohm impedance, this magnetic base antenna delivers reliable FM radio reception for indoor and outdoor use.

Overview

The JUNG FMANT is a passive FM antenna with a magnetic base, designed for stable reception across the FM broadcast band. Its 3-meter RG 58 cable with BNC male connector offers flexible placement, while the stainless steel whip and ABS/metal base ensure durability.

What stands out

• Magnetic base for easy mounting on metal surfaces
• Vertical polarization optimizes FM signal capture
• VSWR below 2:1 for efficient transmission
• Operates from -20°C to +60°C

Technical details

• Antenna type: Magnetic base antenna
• Frequency range: 87.5 - 108 MHz (FM band)
• Impedance: 50 Ohm
• Connector: BNC male
• Cable length: 3 m (RG 58)
• Polarization: Vertical
• Gain: Passive (0 dBi)
• Element length: Approx. 300 mm
• Base diameter: Approx. 80 mm
• Materials: Stainless steel whip, ABS plastic/metal base
• Colour: Black base, silver whip

Our verdict

A robust FM antenna with a magnetic base, ideal for users needing a simple, effective solution for radio reception without complex installation.
