JUNG MMDLS4521WW multimedia-aansluitdoos met TV-, radio- en satellietaansluitingen, alpinowit

The JUNG MMDLS4521WW multimedia socket combines TV, radio, and satellite connections in a single flush-mounted unit, making it ideal for star distribution systems. Its three outputs—IEC male for TV, IEC female for radio, and F-connector for satellite—support frequencies from 5 to 862 MHz for TV/radio and 950 to 2200 MHz for satellite, with low attenuation values of 1.5 dB for TV/radio and 2.5 dB for satellite.

Advantages

This socket features DC pass for satellite (max. 500 mA) and return channel capability (5-65 MHz), ensuring compatibility with modern satellite receivers and interactive services. The Class A shielding and 75 Ohm impedance guarantee excellent signal quality, while the thermoplastic construction in Alpine White provides durability and a clean look.

Suitable for

• Star distribution systems in residential and commercial buildings
• Connecting TV, radio, and satellite receivers
• Flush-mounted installations in standard wall boxes

Key specifications

• Connection type: TV, Radio, Satellite
• Number of outputs: 3
• TV connector: IEC male
• Radio connector: IEC female
• Satellite connector: F-connector
• Frequency range TV/Radio: 5 - 862 MHz
• Frequency range Satellite: 950 - 2200 MHz
• Attenuation TV/Radio: 1.5 dB
• Attenuation Satellite: 2.5 dB
• Shielding class: Class A
• Impedance: 75 Ohm
• DC pass for SAT: Yes (max. 500 mA)
• Return channel: Yes (5-65 MHz)
• Material: Thermoplastic
• Color: Alpine White

Recommendations

For optimal performance, install this socket as an end socket in a star distribution system and use high-quality coaxial cables with F-connectors for satellite connections.
