Kabeladapter DeLOCK 65424

The DeLOCK 65424 Cable Gender Changer adapts a standard VGA connector to a 16‑pin terminal block connection for industrial or specialised installations. It is designed to allow single wires with open cable ends to be connected directly to a display or VGA device via a terminal block instead of a conventional VGA socket. The adapter has a durable housing in black, green and silver and is intended for applications where a reliable wired connection between devices with different VGA configurations is required.

Advantages

This adapter converts a VGA interface to a 16‑pin terminal block, enabling direct connection of individual conductors without additional converters. Its compact construction and mixed‑colour housing support easy identification in installation environments. The DeLOCK 65424 provides a straightforward solution for integrating VGA devices into setups that use terminal block wiring.

Suitable for

• Industrial displays and control panels
• Custom cabling where single wires need to be terminated
• Laboratory and prototyping setups requiring VGA signal access

Key specifications

• Connector 1: VGA
• Connector 2: 16‑pin terminal block
• Product colour: Black, Green, Silver
• Brand: DELOCK
• Manufacturer part number (MPN): 65424
• EAN: 4043619654246

How to use

Connect the VGA plug to the VGA connector on the adapter, then insert and secure individual stripped wires into the corresponding terminals of the 16‑pin block according to your signal assignments. Ensure all screws on the terminal block are tightened to provide secure electrical contact. Verify wiring against pinouts before powering connected equipment.

Recommendations

Use this adapter in low‑to‑moderate mechanical stress environments and follow standard grounding and shielding practices for VGA signals to reduce interference. Confirm pin assignments for your VGA device and check compatibility with the display’s signal levels prior to installation.
