Keenetic Switch 5 PoE+ 5-poorts desktop-switch

The Keenetic Switch 5 stands out with four PoE+ ports that deliver up to 30 W each, making it a compact power hub for IP cameras, access points, and VoIP phones. Its total 60 W PoE budget lets you connect multiple devices without extra power injectors.

Highlights

• 5 Fast Ethernet ports (10/100 Mbps), including 4 PoE+ ports
• IEEE 802.3af/at compliance for PoE and PoE+ devices
• 60 W total PoE power budget, up to 30 W per port
• Unmanaged plug-and-play operation, no configuration needed
• Desktop or wall-mountable metal housing

In daily use

Connect your PoE-powered devices to ports 1-4 and use port 5 as a non-PoE uplink to your router or network. The switch automatically detects PoE devices and supplies the required power. LED indicators show power, link/activity, and PoE status for quick troubleshooting.

Full specifications

• Switching capacity: 1 Gbps
• Packet forwarding rate: 0.74 Mpps
• MAC address table: 2000 entries
• Jumbo frame support: 2 KB
• Power supply: External DC 54V, 1.2A adapter
• Max power consumption: 65 W (with PoE load)
• Operating temperature: 0 to 40 °C
• Operating humidity: 10% to 90% non-condensing
• Networking standards: IEEE 802.3, 802.3u, 802.3x, 802.3af, 802.3at

Final note

A reliable unmanaged PoE+ switch for small deployments, combining simplicity with sufficient power for modern edge devices.
