Lanview LVN128146 Keystone-module

Lanview LVN128146 Keystone-module
Lanview LVN128146 Keystone-module
27,42 €
PDF
PDF
Voorraad 769 Code 1182587 Model LVN128146 Garantie 2 jaar

Bezorging & retourneren

Verwachte bezorgdatum woensdag 9 december
Je blijft op de hoogte via ons uitgebreide trackingsysteem
Betaalopties
BetaalkaartVisaMastercardPayPalApple PayGoogle PayBankoverschrijving

Stel een vraag – de AI-assistent antwoordt direct.

Omschrijving

The Lanview LVN128146 keystone module is an unshielded Cat6a jack designed for patch panels and data outlet installations. Its flat construction and compact dimensions (15 mm × 30 mm × 20 mm) allow installation in standard depth back boxes while offering multiple cable entry directions. The module includes an RJ-45 connector and comes in a metallic finish, providing a simple, space-efficient solution for creating reliable network connections.

Advantages

The flat construction permits versatile mounting options, including flush or angled shutter configurations when used with keystone-compatible faceplates. Its compact size makes it suitable for tight spaces in patch panels and outlets, and the RJ-45 interface ensures compatibility with standard Ethernet cabling. Being an unshielded Cat6a keystone jack, it supports high-speed network links without added shielding hardware.

Suitable for

  • Patch panels in wiring closets and comms racks
  • Wall outlets and faceplates with keystone openings
  • Data, voice and standard Ethernet network terminations
  • Installations requiring multiple cable entry directions

Key specifications

  • Brand: Lanview
  • Model / MPN: LVN128146
  • Type: Unshielded Cat6a keystone jack
  • Connector: RJ-45
  • Construction: Flat
  • Color / Finish: Metallic
  • Dimensions (W × D × H): 15 mm × 30 mm × 20 mm
  • Package quantity: 1 piece
  • EAN: 5704174319085

How to use

Terminate the appropriate Cat6a UTP cable onto the keystone module following standard color-code wiring (T568A or T568B) and secure the conductors per the module's termination style. Insert the keystone into a compatible faceplate or patch panel slot until it snaps into place. When mounting in a standard depth back box, orient the module to accommodate the desired cable entry direction, then connect patch cords to the RJ-45 port for network access.

Recommendations

Use the Lanview LVN128146 in dry, indoor environments and pair it with compatible keystone faceplates or patch panels. For best performance, follow Cat6a cabling practices — maintain proper bend radius, avoid untwisting pairs excessively during termination, and choose the matching wiring standard across the link.
Belangrijkste kenmerken
  • Patch panels in wiring closets and comms racks
  • Wall outlets and faceplates with keystone openings
  • Data, voice and standard Ethernet network terminations
  • Installations requiring multiple cable entry directions
  • Brand: Lanview
  • Model / MPN: LVN128146
  • Type: Unshielded Cat6a keystone jack
  • Connector: RJ-45
  • Construction: Flat
  • Color / Finish: Metallic
  • Dimensions (W × D × H): 15 mm × 30 mm × 20 mm
  • Package quantity: 1 piece
  • EAN: 5704174319085

Specificaties

Specificaties
Aansluiting 1
RJ-45
Aansluiting 2
RJ-45
Aantal per verpakking
1 pc(s)
AWG-draaddikte
22/24
Bekabelingstechnologie
10GBase-T
Breedte
15 mm
Breedte verpakking
70 mm
Certificering
TIA-568-C2, ISO11801
Diepte
30 mm
Diepte verpakking
50 mm
Frequentie
500 MHz
Geharmoniseerd Systeem (HS)-code
85369010
Geslacht aansluiting 1
Vrouwelijk
Geslacht aansluiting 2
Mannelijk
Gewicht
10.332 g
Gewicht verpakking
14.082 g
Hoogte
20 mm
Hoogte verpakking
100 mm
Kabelafscherming
U/UTP (UTP)
Materiaal behuizing
Metaal
Ondersteunde kabeltypen
Cat6a
Productkleur
Metaalachtig
Type uitvoering
Plat
