LINGG Lola Carre KNX touchsensor 2-voudig met LED, aluminium Q6100211

In modern KNX building automation, the LINGG Lola Carre 2-gang touch sensor with integrated LEDs offers intuitive control of lighting, blinds, and scenes from a sleek aluminium front plate. Designed for flush-mounted installation, it fits standard European wall boxes and is configured via ETS software.

Key specifications

• Product type: KNX touch sensor
• Number of control surfaces: 2
• Integrated LED: Yes, for status and orientation
• Bus system: KNX (21-30V DC)
• Design line: Lola Carre
• Colour: Aluminium
• Material (front plate): Aluminium
• Mounting type: Flush-mounted
• Configuration software: ETS
• Functions: Switching, dimming, blind/shutter control, value transmitter, scene recall
• Protection class: IP20
• Operating temperature: 0°C to +45°C
• Relative humidity: Max. 90% non-condensing
• Installation depth (electronics module): Approx. 25 mm

Why choose it

The Lola Carre touch sensor combines a minimalist aluminium design with reliable KNX communication. The integrated LEDs provide clear visual feedback, making it easy to locate and operate even in low light. Its compact electronics module simplifies installation in standard flush-mounted boxes.

Ideal use cases

• Residential smart homes for lighting and blind control
• Office buildings requiring scene-based lighting
• Hotel rooms for guest-friendly control of multiple functions
• Renovation projects with existing KNX bus infrastructure

Good to know

The sensor is configured using ETS, the standard KNX engineering tool. It operates directly from the KNX bus voltage, eliminating the need for an additional power supply. The aluminium front plate is durable and complements modern interior designs.
