Makita LVH800 laserontvanger

The Makita LVH800 Laser Receiver is a high-performance detector designed for use with Makita rotary laser levels. It offers exceptional detection range and accuracy, making it ideal for construction, surveying, and outdoor leveling tasks. With a working diameter of up to 800 m and fine accuracy of ±1.0 mm, this receiver ensures reliable performance even in bright sunlight. The dual LCD displays and adjustable volume buzzer provide clear visual and audible feedback for efficient operation.

Advantages

Exceptional detection range of up to 800 m diameter ensures versatility on large job sites. Fine accuracy of ±1.0 mm delivers precise leveling results. Dual front and rear LCD screens allow easy reading from any angle. Adjustable volume buzzer provides clear audible alerts in noisy environments. IP54 rating protects against dust and water splashes for durability on construction sites. Long battery life of approximately 70 hours minimizes downtime. Auto shut-off after 30 minutes of inactivity conserves battery power.

Suitable for

• Construction professionals using rotary laser levels for grading, excavation, and foundation work
• Surveyors requiring precise elevation measurements over long distances
• Landscapers and contractors for outdoor leveling and alignment tasks
• Interior fit-out specialists for ceiling and partition installation

Key specifications

• Detection Range (Diameter): Up to 800 m
• Accuracy (Fine): ±1.0 mm
• Accuracy (Coarse): ±2.5 mm
• Display: Front & Rear LCD
• Audio Indicator: Adjustable Volume Buzzer
• Power Source: 2 x AA Batteries
• Battery Life: Approx. 70 hours
• Auto Shut-off: Yes (after 30 min inactivity)
• IP Rating: IP54
• Mounting: Rod Clamp (included)
• Operating Temperature: -10°C to +50°C
• Beam Detection: Red Rotary Laser
• Housing Material: Durable Plastic
• Low Battery Indicator: Yes

Recommendations

For optimal performance, use the LVH800 with Makita rotary laser levels. Always ensure batteries are fresh for maximum range and accuracy. The included rod clamp allows quick attachment to grade rods or tripods.
