Mean Well HLG-150H-24B 151,2W 24V 6,3A LED-voeding IP67

The Mean Well HLG-150H-24B is a high-efficiency, single-output switching power supply designed for LED lighting and industrial applications. With a compact metal housing and IP67 rating, it is suitable for both indoor and outdoor use. The unit delivers a constant voltage of 24V DC with a maximum output current of 6.3A, providing 151.2W of power. It features active PFC, 3-in-1 dimming (0-10V, PWM, resistance), and comprehensive protections.

Advantages

High efficiency up to 93% reduces energy loss and heat generation. Wide input voltage range (90-305V AC) ensures global compatibility. IP67 rating allows installation in harsh environments. Built-in active PFC meets harmonic current regulations. 3-in-1 dimming function enables flexible lighting control.

Suitable for

• LED lighting systems (indoor and outdoor)
• Industrial automation equipment
• Signage and decorative lighting
• Any application requiring a rugged, weatherproof 24V power supply

Key specifications

• Output Power: 151.2W
• Output Voltage: 24V DC
• Output Current: 6.3A
• Input Voltage: 90-305V AC / 127-431V DC
• Input Frequency: 47-63Hz
• Efficiency: 93%
• Dimming: 3-in-1 (0-10V, PWM, Resistance)
• IP Rating: IP67
• Hold-up Time: 16ms at full load (230VAC)
• Operating Temperature: -40 to +80°C
• Protections: Short circuit, overload, over voltage, over temperature
• Certifications: UL, CUL, TUV, CE, CB, RCM, EAC, KC, CCC

Recommendations

For optimal performance, ensure proper ventilation and avoid exceeding the rated output. Use with compatible LED drivers or loads that accept 24V DC constant voltage input.
