MENNEKES 4246 CEE inbouwcontactdoos 16A 5P 6h 400V IP44 rood

CEE flush-mounted socket for industrial power distribution, rated 16 A with 5 poles (3P+N+PE) and 400 V. The 6h earth contact position prevents connection of devices with different voltage or frequency, and the IP44 protection allows use in damp or dusty environments.

Advantages

Hinged cover protects the socket when not in use. Screw terminals provide secure wiring. Polyamide housing and brass contacts ensure durability. Red colour identifies 400 V three-phase supply.

Suitable for

• Industrial workshops
• Commercial kitchens
• Construction sites
• Outdoor installations with temporary power needs

Key specifications

• Current rating: 16 A
• Voltage: 400 V (380–415 V)
• Poles: 5 (3P+N+PE)
• Earth contact position: 6h
• Ingress protection: IP44
• Mounting: Flush-mounted
• Connection: Screw terminals
• Housing material: Polyamide (PA6)
• Contact material: Brass
• Colour: Red
• Standards: IEC 60309-1, IEC 60309-2
• Operating temperature: -25°C to +40°C
• Cable entry: Rear

Recommendations

For reliable three-phase power connections in industrial environments, pair with a compatible CEE plug with 6h earth position.
