METZ Connect MMT371A115 printplaatbus 4-polig 3,81mm raster schroefklem groen

Connecting wires to a printed circuit board often means choosing between a secure hold and easy servicing. The METZ Connect MMT371A115 PCB socket solves this by combining a screw terminal connection with through-hole mounting, giving you a reliable, vibration-resistant link that can be disconnected and reconnected whenever needed. With a 3.81 mm pitch and 4 poles, it fits compact PCB layouts while handling up to 8 A and 160 V.

Who is it for

This socket is built for engineers, technicians, and hobbyists working on industrial controls, automation systems, or custom electronics. It suits anyone who needs a durable board-level connector that can be wired in the field without special tools. Whether you are prototyping a new design or maintaining existing equipment, the MMT371A115 offers a straightforward solution.

Main features

• 4-pole PCB socket with 3.81 mm pitch for compact, high-density layouts
• Screw terminal connection accepts solid or stranded wire from 0.2 to 1.5 mm² (AWG 24–16)
• Through-hole technology (THT) mounting for strong mechanical anchoring to the PCB
• Rated for 8 A and 160 V (IEC), suitable for a wide range of low-voltage applications
• Horizontal wire entry keeps the profile low and simplifies cable routing
• Polyamide (PA) housing with UL94 V-0 flammability rating for safety
• Copper alloy contacts with tin plating for reliable conductivity and corrosion resistance
• Wide operating temperature range from -40 to +105 °C

Specifications

• Brand: METZ Connect
• Model: MMT371A115
• MPN: MMT371A115
• EAN: 4251394621999
• Number of poles: 4
• Pitch: 3.81 mm
• Connection type: Screw terminal
• Mounting type: Through-hole technology (THT)
• Rated voltage (IEC): 160 V
• Rated current (IEC): 8 A
• Wire size (solid): 0.2–1.5 mm² (AWG 24–16)
• Wire size (stranded): 0.2–1.5 mm² (AWG 24–16)
• Wire stripping length: 5 mm
• Insulation material: Polyamide (PA)
• Contact material: Copper alloy, tin-plated
• Operating temperature range: -40 to +105 °C
• Colour: Green
• Orientation: Horizontal (wire entry parallel to PCB)
• Screw thread: M2
• Flammability rating: UL94 V-0

Tips

For a secure connection, strip the wire to 5 mm and tighten the screw to the recommended torque. Use a screwdriver that matches the M2 screw head to avoid damage. When soldering the through-hole pins, ensure the PCB holes are correctly aligned with the 3.81 mm pitch to prevent stress on the housing.
