MITON MT-P1280-D21 waterdichte aansluitdoos IP65 120x80x55mm lichtgrijs

The MITON MT-P1280-D21 is a high-quality hermetic junction box designed for demanding outdoor, industrial, and telecommunications applications. Manufactured from durable ABS plastic with a light grey (RAL 7035) finish, this IP65-rated enclosure provides reliable protection against dust and water ingress. Its compact external dimensions of 120 x 80 x 55 mm and internal dimensions of approximately 114 x 74 x 50 mm offer ample space for wiring, PCBs, or DIN rail components.

Advantages

Robust IP65 protection ensures suitability for harsh environments. The UV-resistant ABS material withstands prolonged sun exposure, while the EPDM gasket maintains a reliable seal. The screw-on lid with four screws provides secure closure, and the smooth walls allow for custom drilling or gland installation. Impact resistance rated IK07 adds extra durability.

Suitable for

• Outdoor electrical installations
• Industrial control systems
• Telecommunications equipment housing
• Sensor and actuator junction boxes
• DIY electronics projects requiring weatherproofing

Key specifications

• Enclosure Type: Hermetic / Waterproof
• Material: ABS Plastic
• IP Rating: IP65
• External Dimensions (L x W x H): 120 x 80 x 55 mm
• Internal Dimensions (L x W x H): 114 x 74 x 50 mm (approx.)
• Color: Light Gray (RAL 7035)
• Lid Type: Screw-on (4 screws)
• Seal Material: EPDM Gasket
• Mounting Type: Wall Mountable
• UV Resistance: Yes
• Operating Temperature Range: -20°C to +70°C
• Impact Resistance: IK07
• Cable Entry: Smooth walls for custom drilling/gland installation
• Internal Mounting: Bosses for PCB/DIN rail mounting
• Wall Thickness: 3 mm
• Compliance: RoHS Compliant

Recommendations

For best results, use appropriate cable glands and ensure the gasket is properly seated before tightening the lid screws. This junction box is ideal for protecting sensitive electronic components in wet or dusty environments.
