MITON MT-P13G opbouw aftakdoos, grijs (RAL 7035), IP65, IK07, 130x130x75 mm

The MITON MT-P13G is a robust surface-mounted junction box designed for reliable electrical installations in both indoor and outdoor environments. Manufactured from high-quality ABS plastic, this enclosure offers excellent durability and protection against dust and water ingress with an IP65 rating. Its grey colour (RAL 7035) ensures a neutral appearance suitable for various settings.

Advantages

This junction box provides a secure and weatherproof housing for cable connections and terminations. The screw-on lid with four screws ensures a tight seal, while the flexible membrane knockouts allow for easy cable entry without the need for additional glands. The box is UV resistant, halogen-free, and self-extinguishing, making it a safe choice for industrial and telecommunications applications.

Suitable for

• Electrical installations in residential, commercial, and industrial buildings
• Outdoor applications such as gardens, terraces, and building exteriors
• Telecommunications and network infrastructure
• Use as a junction or connection box for cable management

Key specifications

• Product Type: Surface-Mounted Junction Box
• Material: ABS Plastic
• Colour: Grey (RAL 7035)
• Protection Rating: IP65
• Impact Resistance: IK07
• External Dimensions (L x W x H): 130 x 130 x 75 mm
• Internal Dimensions (L x W x H): Approx. 122 x 122 x 68 mm
• Mounting Type: Surface
• Lid Fastening: Screw-on (4 screws)
• Number of Cable Entries: 4-6 flexible membrane knockouts
• Operating Temperature: -25°C to +60°C
• UV Resistant: Yes
• Halogen-Free: Yes
• Flame Retardancy: Self-extinguishing
• Application: Electrical installations, outdoor/indoor, industrial, telecommunications
• Gland Type: Flexible membrane for cable entry

Recommendations

For optimal installation, ensure the mounting surface is clean and dry. Use appropriate cable glands or seals if additional protection is required. This junction box is ideal for use with MITON connectors and accessories.
