MITON MT-P1280-D8-B 8-uitgang multiswitch met 9 ingangen, DiSEqC 2.0, F-stekker

The MITON MT-P1280-D8-B is a high-performance multiswitch designed for satellite and terrestrial signal distribution. With 9 inputs (8 satellite, 1 terrestrial) and 8 outputs, it enables the distribution of signals to multiple receivers or rooms. The unit supports DiSEqC 2.0 control protocol and is compatible with DiSEqC 1.0/1.1, ensuring seamless integration with existing systems. Its metal housing and wall-mountable design make it a durable and space-saving solution for professional installations.

Advantages

This multiswitch offers zero dB satellite path loss and 8-10 dB terrestrial path gain, ensuring strong signal integrity. The high input and output isolation (>25 dB) minimizes interference between ports. With support for 13V/18V LNB switching and 0/22kHz tone, it is compatible with a wide range of LNBs and receivers. The unit can be powered via an external 18V DC power supply or directly from a receiver, providing flexibility in installation.

Suitable for

• Satellite TV distribution in multi-room setups
• Combined satellite and terrestrial signal distribution
• Professional and residential AV installations

Key specifications

• Number of Inputs: 9 (8 Satellite, 1 Terrestrial)
• Number of Outputs: 8
• Satellite Input Frequency Range: 950-2150 MHz
• Terrestrial Input Frequency Range: 47-862 MHz
• Control Protocol: DiSEqC 2.0 (compatible with 1.0/1.1)
• Impedance: 75 Ohm
• Connector Type: F-type
• Operating Temperature: -20°C to +50°C
• Housing Material: Metal
• Mounting Type: Wall-mountable

Recommendations

For optimal performance, use high-quality F-type connectors and ensure proper grounding. The multiswitch can be powered by a compatible receiver or an external 18V DC power supply (not included). Verify LNB current requirements do not exceed 500 mA per input.
