NEO TOOLS Neo 35-012 digitale multimeter CAT II 600V met LCD, diode- en doorgangstest

Electrical troubleshooting can be frustrating without a reliable meter. The NEO TOOLS Neo 35-012 digital multimeter gives you accurate readings for voltage, current, resistance, diode, continuity, and transistor hFE in one compact, manual-ranging tool. Whether you're a hobbyist or a professional, this meter helps you diagnose circuits quickly and safely.

Who is it for

Ideal for electricians, electronics enthusiasts, students, and DIYers who need a dependable multimeter for testing outlets, batteries, wiring, components, and more. Its CAT II 600V safety rating makes it suitable for indoor applications like household appliances and electronic devices.

Main features

• Manual-ranging digital multimeter with 1999-count LCD display
• Measures DC voltage up to 600V and AC voltage up to 600V
• Measures DC current up to 10A in six ranges
• Measures resistance from 200Ω to 2MΩ
• Diode test and audible continuity buzzer for quick checks
• Transistor hFE test for NPN and PNP transistors
• Overload protection on all ranges
• Powered by a single 9V (6F22) battery (included)
• Durable ABS housing with a compact, handheld design

Specifications

• Display: 1999-count LCD
• DC voltage ranges: 200mV / 2V / 20V / 200V / 600V
• AC voltage ranges: 200V / 600V
• DC current ranges: 200µA / 2mA / 20mA / 200mA / 10A
• Resistance ranges: 200Ω / 2kΩ / 20kΩ / 200kΩ / 2MΩ
• Diode test: Yes
• Continuity test: Yes (with buzzer)
• Transistor hFE test: Yes
• Safety rating: CAT II 600V
• Power source: 1x 9V (6F22) battery
• Operating temperature: 0°C to 40°C
• Housing material: ABS plastic
• Included accessories: test leads, 9V battery, user manual

Tips

Always select the correct range before measuring to avoid damage. For continuity, the buzzer sounds when resistance is below about 30Ω. Replace the battery when the display shows a low-battery indicator to maintain accuracy.
