OBO BETTERMANN Connect 45 STD-D3SC SRO3 3-voudig randaarde stopcontact, 33° gehoekt, zwart 6120509

This OBO BETTERMANN STD-D3SC SRO3 socket outlet stands out with its 33° angled Schuko sockets, engineered for the Connect 45 system. The angled orientation reduces cable clutter and improves access in tight installation environments, making it a practical choice for modern office and commercial spaces.

Highlights

• 3 Schuko (Type F) sockets with increased touch protection
• 33° angled orientation for easier plug access
• Snap-in mounting for quick installation in Connect 45 compatible ducts and boxes
• Halogen-free polycarbonate/ABS construction in black (RAL 9005)

In daily use

The socket outlet is rated for 250 V AC and 16 A, suitable for standard office equipment. Its plug-in terminals accept solid or stranded conductors up to 2.5 mm², simplifying wiring. The matt black finish blends seamlessly into modern interiors, while the halogen-free material supports safer building environments.

Full specifications

• Number of sockets: 3
• Socket type: Schutzkontakt (Type F, CEE 7/3)
• Socket orientation: 33° angled
• Rated voltage: 250 V AC
• Rated current: 16 A
• Connection type: 3-pole plug-in terminal
• Max. cable cross-section: 2.5 mm²
• Material: Polycarbonate (PC) / ABS
• Colour: Black (RAL 9005)
• Surface finish: Matt
• Halogen-free: Yes
• Increased touch protection: Yes
• Mounting type: Snap-in
• Protection degree: IP20
• System compatibility: OBO Bettermann Connect 45

Final note

Designed for device installation ducts, desk boxes, service poles, and underfloor systems, this outlet integrates reliably into the Connect 45 ecosystem.
